BS4568 BS31 Circular Junction Box Malleable One Way Terminal

BS4568 BS31 Circular Small Large Gi Conduits And Accessories Malleable One Way Terminal Box

BS4568   BS31 circular malleable one way terminal box   Circular box GI conduit fittings

Description:

BS4568 circular malleable one way terminal box GI conduit fittings

Marking: TOPELE, as customer request, can open mold as customer own brand.

Material: Malleable Iron

Finish: Hot-dip Galvanized, Aluminum

Standard: BS4568/BS31

Size: 20mm, 25mm, 3/4”, 1”

60.3mm Internal Diameter x 25.4mm Deep Tapped M4 in mm sizes and 2BA in imperial sizes of 50.3mm with tapped hole in base for earthing screw.

Note:

1. The base has tapped holes for grounding screws.

2. Covers or fixing screws are not supplied unless ordered.

3. Order 3/4" & 1" when using with BS31 Conduits.

4. Order 20mm,25mm when using with BS4568 Conduits.

5. BS31 boxes also available in cast Iron & finish galvanized coating.

6. Box Covers are available 1.0/1.2mm thickness, finish Hot-Dipped Galvanized;

7. Each box is supplied C/W one regulation Tap Earth Terminal Hole in base;

8. Small and large terminal Boxes available;

9. Deep pattern Boxes available;

10. Full range of Conduit Fittings(Saddles) available to suit different site needs;

11. A good range of other supporting catheter fittings is available.

Applications:

BS4568 circular malleable one way terminal box GI conduit fittings

to protect conductors in threaded rigid conduit, act as pull and splice boxes, interconnect lengths of conduit, change conduit direction and provide access to conductors for maintenance and future system change.

It allows the wires to be connected to the junction box, storing the excess in the box and providing protection for the wires.
